Pivot Cycles Mach 4 SL World Cup XX1 AXS w/Fox Live Valve

Pivot Cycles Mach 4 SL World Cup XX1 AXS w/Fox Live Valve
  • Color: Greystorm
  • Color: Black Sunshine
  • Color: Cherry
  • Color: Deep Lake Blue
  • Color: Stealth
$8,500.00 - $12,999.00
$12,999.00
Please select options
This product is not available for online purchase. Please call us or visit our store.

Details

Gravity Defying Cross Country Rocket Ship

The all-new Mach 4 SL is designed to let World Cup level athletes capitalize on every inch of increasingly technical courses and generate speed where others hesitate. Our engineers have pushed the boundaries in every conceivable metric of cross-country performance. It's the lightest, fastest 100mm travel XC race bike we've ever developed. Go ahead, turn yourself inside out and leave it all out on the race course because the new Mach 4 SL leaves nothing on the table.

Weighty Goals
Cross country racers know that every gram counts. Pivot's engineers didn't set out to cut a few grams – they insisted on slashing hundreds. Starting at 1845 grams, the Mach 4 SL takes a front row seat in the ultralight full suspension category and has the best stiffness to weight ratios we've ever created. The new Mach 4SL is over 300 grams lighter than its feathery predecessor, the Mach 429 SL - that's 3/4 of a pound! Optimized tube shapes, a more compact frame design, exotic hi-mod materials, and a dual upright, reinforced swingarm push strength and stiffness while allowing weight to be shaved everywhere. More weight evaporates with an integrated headset and race-proven carbon suspension bearing pockets that leave almost no metal in the frame. Steep climbs and sharp accelerations never felt so good – or fast.

Short or Tall, it Fits Them All
Proper fit is critical to maximizing our body's output, so we made sure the Mach 4 SL fits the widest range of riders and all genders without compromise. The extra-small size fits riders down to 4"10" with a lower standover height than even our Mach 4 Carbon with 27.5" wheels, and the extra-large size fits riders up to 6'7" tall. A shorter stack, longer reach, and steeper seat angle put you in a powerful position to churn out the watts mile after mile. Size-specific carbon layups and shock tunes make sure all riders experience the same cutting edge performance and ride across the size range.

- Frame weight starting at 1845 grams (4.0 lb.) and 20.9 lb. (9.4kg) complete—(size medium with XTR World Cup Build)
- 100mm of renowned dw-link suspension tuned for XC race and trail performance
- Designed to work with 100-120mm travel forks
- Full Fox Live Valve integration
- World Cup caliber full carbon frame featuring leading edge materials and Pivot's proprietary Hollow Core Internal Molding Technology
- Progressive XC geometry for the most demanding World Cup courses
- 29-inch wheels for the fastest laps and superior rollover in technical terrain
- Full-length internal cable routing via Pivot's exclusive, easy-to-maintain Cable Port System
- Internal dropper post compatible
- Large water bottle fits inside all size frames – even XS-XL frame fits 2 bottles inside the front triangle
- Lightweight, cold forged alloy linkages with Enduro Max Cartridge Bearings
- Fox Kashima Factory shock, custom-tuned specifically for the Mach 4 SL
- Highly durable frame and swingarm protection
- Boost 12 x 148mm rear spacing
- Available in sizes XS, S, M, L, XL for riders between 4'10" and 6'7"

Geometry

Geometry Chart:
X-SmallSmallMediumLargeX-Large
A- Seat Tube Length (C-T) 35.6 cm 39.4 cm 41.9 cm 45.7 cm 50.2 cm
BTop Tube Length 57.1 cm 58.4 cm 61.3 cm 63.6 cm 66.6 cm
CHead Tube Length 8.5 cm 9.5 cm 10.8 cm 11.9 cm 14.0 cm
DHead Tube Angle 68.50° 68.50° 68.50° 68.50° 68.50°
ESeat Tube Angle (Eff.) 74.50° 74.50° 74.50° 74.50° 74.50°
FChain Stay Length 43.1 cm 43.1 cm 43.1 cm 43.1 cm 43.1 cm
GBottom Bracket Height 32.5 cm 32.5 cm 32.5 cm 32.5 cm 32.5 cm
HStandover Height 61.3 cm 65.2 cm 68.4 cm 68.7 cm 71.1 cm
IWheelbase 109.3 cm 110.6 cm 113.6 cm 116.0 cm 119.3 cm
Stack 58.0 cm 59.0 cm 60.2 cm 61.2 cm 63.1 cm
Reach 40.5 cm 41.5 cm 44.0 cm 46.0 cm 48.5 cm

Part Numbers

Option UPC MPN Store SKU
Greystorm / X-Small 196338061735 004SLV229CXXEWLGRYXSSTDLN
Greystorm / Small 196338061674 004SLV229CXXEWLGRYSMSTDLN
Greystorm / Medium 196338061643 004SLV229CXXEWLGRYMDSTDLN
Greystorm / Large 196338061612 004SLV229CXXEWLGRYLGSTDLN
Greystorm / X-Large 196338061704 004SLV229CXXEWLGRYXLSTDLN
Black Sunshine / X-Small 196338061582 004SLV229CXXEWLBLSXSSTDLN
Black Sunshine / Small 196338061520 004SLV229CXXEWLBLSSMSTDLN
Black Sunshine / Medium 196338061490 004SLV229CXXEWLBLSMDSTDLN 210000010694
Black Sunshine / Large 196338061469 004SLV229CXXEWLBLSLGSTDLN 210000017251
Black Sunshine / X-Large 196338061551 004SLV229CXXEWLBLSXLSTDLN
Cherry / X-Small 196338047395 004SLV129CXXEWLCHYXSSTDLN
Cherry / Small 196338047357 004SLV129CXXEWLCHYSMSTDLN
Cherry / Medium 196338047333 004SLV129CXXEWLCHYMDSTDLN
Cherry / Large 196338047319 004SLV129CXXEWLCHYLGSTDLN
Cherry / X-Large 196338047371 004SLV129CXXEWLCHYXLSTDLN
Deep Lake Blue / X-Small 196338047494 004SLV129CXXEWLDPLXSSTDLN
Deep Lake Blue / Small 196338047456 004SLV129CXXEWLDPLSMSTDLN
Deep Lake Blue / Medium 196338047432 004SLV129CXXEWLDPLMDSTDLN
Deep Lake Blue / Large 196338047418 004SLV129CXXEWLDPLLGSTDLN
Deep Lake Blue / X-Large 196338047470 004SLV129CXXEWLDPLXLSTDLN
Stealth / X-Small 196338047593 004SLV129CXXEWLSTLXSSTDLN
Stealth / Small 196338047555 004SLV129CXXEWLSTLSMSTDLN
Stealth / Medium 196338047531 004SLV129CXXEWLSTLMDSTDLN
Stealth / Large 196338047517 004SLV129CXXEWLSTLLGSTDLN
Stealth / X-Large 196338047579 004SLV129CXXEWLSTLXLSTDLN
